AUD-PRE126
AUDAC - 2 ZONE 6 CHANNEL STEREO PRE AMPLIFIER
- Model — PRE126
- Category — Commercial Audio Products/PA Amplifiers
Full Specifications
AUD-PRE126 — detailed spec
Inputs2 x Balanced Microphone, 1 x Stereo Balanced Line, 3 x Stereo Unbalanced Line
BluetoothIntegrated (mixed with Ch 3)
Front Input3.5 mm Jack (mixed with Ch 4)
Priority MuteContact input
Outputs2 x Balanced Stereo
Microphone Sensitivity-6 dB ~ -50 dB
Line Sensitivity-20 dB ~ +4 dB
Microphone EQ High15 dB (12.5 kHz)
Microphone EQ Mid15 dB (2.5 kHz)
Microphone EQ Low15 dB (80 Hz)
Phantom Power15 V DC
Output EQ Treble15 dB (2.5-20 kHz)
Output EQ Bass15 dB (100 Hz)
Frequency Response20 Hz - 20 kHz
Signal to Noise Ratio> 90 dB
THD+N< 0.05%
Crosstalk> 70 dB
Power Supply100 - 240 V AC, 50 - 60 Hz
Power Consumption12 W
Dimensions482 x 44 x 335 mm (W x H x D)
Weight4.1 kg
Unit Height1 HE
