DEKK DK8425A — Ceiling Mount Brackets
DEKK Long Drop Dual Screen Ceiling Bracket
- Model: DK8425A
- Category: Brackets & Enclosures/Ceiling Mount Brackets
Full Specifications
DK8425A: detailed spec
Bracket TypeCeiling mount, dual/back-to-back screen, long drop Ceiling Plate: 200 mm, rotation +60 to -60 degrees Pole Diameter: 48 mm (upper) / 40 mm (lower) Ceiling-to-Mount Drop (Short): 778-1128 mm Ceiling-to-Mount Drop (Extended): 560-910 mm Max VESA (Horizontal, per screen): 200-400 mm Max VESA (Vertical, per screen): 200-400 mm Overall Width (Max): 480 mm Overall Bracket Height: 435 mm Tilt: +5 to -20 degrees Swivel (Display Bracket): -3 to +3 degrees Rotation (Ceiling Pole): +/- 180 degrees
